VVG - Vacuum Generators
Vacuum Generators
Vacuum Generators
Product FeaturesProduct Features
  • Max. vacuum pressure: -90kPa
  • Stainless steel 316L construction
  • MMHG (Torr) vacuum generators
  • With a minimum source nitrogen pressure of 90 psig
  • 100% helium leak test
ParameterParameter
  • Max. Vacuum pressure
    -90kPa
  • Inlet pressure at limiting vacuum pressure
    5 bar
  • Flow at limiting vacuum pressure
    37L/min
  • Max. Working pressure
    10 bar
  • Temperature range
    0~150℃
  • Source Gas
    Nitrogen
  • Surface finish
    0.4μin.Ra / 0.25μin.Ra 可选
  • Inlets / Outlets
    1/4" 1/2" VFS Fitting
Material QualityMaterial Quality
  • Body
    SS 316L
