All-Welded Check Valves

UHP

UHP

Current Location

VUCV - All-Welded Check Valves

All-Welded Check Valves

All-Welded Check Valves

Product FeaturesProduct Features

All-welded design body with minimal dead space
Cracking pressure less than 2 psig
Strong durability as well as corrosion resistance for long cycle life
Elgiloy® spring material with free noise in the process of using

ParameterParameter

Working Pressure
3000 psig
Cracking Pressure
<2 psig
Working Temperature
-10~80℃
Flow Capacity
Cv=0.55（1/4”）， Cv=0.70（1/2”)

Material QualityMaterial Quality

Body
SS 316L
Sprting
Elgiloy®
O-ring
FKM
Seal Materials
EPDM / Kalrez® (FFKM)
