VUBV2 - Bellows Valves
Bellows Valves
Bellows Valves
Product FeaturesProduct Features
  • Tube welding and VFS fitting connection
  • Easy to clean
  • Excellent airtightness characteristics
  • EP treatment is standard for all wetted surfaces
  • All-metal seal to atmosphere
ParameterParameter
  • Pneumatic Pressure
    Vacuum 375 psig (25.8bar)
  • Surface finish
    10μin. Ra
  • Working Temp
    -22oF ~ 180oF (-30oC ~ 82oC)
  • Internal Leakage Allowance
    <1x10-9 mbar I/s He
  • External Leakage Allowance
    <1x10-9 mbar I/s He
Material QualityMaterial Quality
  • Bellows
    SUS316L / Hastelloy®
  • Body
    316L
  • Seat packing
    PCTFE
  • Seat
    PCTFE, Vespel® (optional)
