VBV1 - Ball Valves

Ball Valves

Ball Valves

Product FeaturesProduct Features

Bi-directional flow (fully opened or fully closed)
Directional handle indicating on-off position
Allow for panel mounting
Single piece ball stem to eliminate backlash
One piece body to eliminate multiple seal points
Unique, top-loaded capsule paching allows reliable switching
Tested for use with oxygen

ParameterParameter

Pressure Rating
max. 206 bar
Temperature range
-54℃ to 148℃
Leak rate
0.1std cc/min@1000psig(69bar)N2
Orifice
Φ2.4~10.3 mm (根据端口)
Inlets / Outlets
see ordering info

Material QualityMaterial Quality

Body
316
Seat Valve
PTFE
