VBV3 - Ball Valves

Ball Valves

Ball Valves

Product FeaturesProduct Features

Bi-directional flow (fully opened or fully closed)
Directional handle indicating on-off position
Low operating torque
Encapsulated seat
Single piece ball stem to eliminate backlash
One piece body to eliminate multiple seal points.
Unique, top-loaded capsule packing allows reliable switching
Tested to use with oxygen

ParameterParameter

Pressure
1000 psig @ 38oC
Orifice
（6mm/1/4”Tube fitting, 1/4NPT）Ф5mm
Orifice
（10mm/3/8”Tube fitting）Ф7 mm
Orifice
（12mm/1/2”Tube fitting, 1/2NPT）Ф9 mm
Temperature range
-42oC to +204oC
Leak rate
0.1 std cc/min
Inlets / Outlets
see ordering info

Material QualityMaterial Quality

Body
316
Seat Valve
PTFE
