VNV - Needle Valves
Needle Valves
Needle Valves
Product FeaturesProduct Features
  • Live-loaded packing system
  • Vee stem, regulating stem, soft-seat stem are optional
  • Compact design
  • Panel mounting
  • Straight, angle, and cross flow patterns
  • Working presssure up to 5000 psig (345 bar)
ParameterParameter
  • Inlet pressure
    max. 206 bar (3000 psig)
  • Inlets / Outlets
    see ordering info
  • Temperature range
    -54℃ to +232℃
  • Leak rate
    0.1 cc/min
Material QualityMaterial Quality
  • Body
    316
  • Seat Valve
    PCTFE
  • Filter
    316
Download
