VPT - Pressure Transmitter

Pressure Transmitter

Pressure Transmitter

Product FeaturesProduct Features

High precision
Stainless steel construction
Available with a variety of output signals
Broad selection of pressure ranges, pressure references: gauge (vacuum, positive) and absolute
Repeatability, reliability, and stability
Anti-interference
Vabration and shock resistance

ParameterParameter

Pressure range (Standard)
0~0.6bar / 0~600bar
Pressure range (Explosion-proof)
0~5bar / 0~600bar
Supply voltage
DC 12V~24V
Output signal
4~20 mA
Ambient Temperature
-20℃ to +85℃
Accuracy
±0.35% FS (5-100 bar)，±0.5% FS (其它)
Zero point shift
±0.02% FS
Sensitivity shift
±0.015% FS
Response time
≤2.5 ms
Electrical connection
Wire / Hirschmann
connection
1/4”NPT(M)
Explosion-proof
Exd II CT6

Material QualityMaterial Quality

Body
304 / 316
Diaphragm
316L
外壳材质
304 / 316
