VDV36UB - Diaphragm Valve

Diaphragm Valve

Diaphragm Valve

Product FeaturesProduct Features

Excellent degassing characteristics is achieved through minimized flow paths by combining 2 of VDV32、VDV33 diaphragm valves together in one valve body
Fewer welds over standard valve alignments
Reduces space requirements
Compact tubing arrangement
Dead space free configuration

ParameterParameter

Max. Working Pressure
150 psig (10 bar) 3000 psig (206bar) 可选
Pneumatic Operating Pressure
58~87psig (4-6bar)
Max. Working Temp.
14oF ~ 104oF (-10oC ~ 40oC)
Surface finish
10μin. Ra
Internal Leakage Allowance
<1x10-9 mbar I/s He
External Leakage Allowance
<1x10-9 mbar I/s He
Flow capacity
Cv=0.3 (低压) Cv=0.1 (高压)

Material QualityMaterial Quality

Body
316L EP / 316L secondary remelt
Diaphragm
Elgiloy®
Seat packing
PCTFE
