VAS200 - Alarm System

Alarm System

Alarm System

Product FeaturesProduct Features

Real-time display of gas pressure numberical display
High and low voltage alarm function
The color of the value box changes to red when warning, and there is a buzzer alarm
There is a trunk line. Action output signal for pressure alarm
High and low alarm values can be set according to field requirements
Realized real-time count automatically saved
With gas curve analysis function
Alarm fault signal automatically saved

ParameterParameter

Type of monitoring
unrestricted
Supply voltage
AC220V（110）/ 50Hz
Power consumption
30W
Input capacity
max. 20 channels
Input signal
4-20 mA
Output contact
2
Output voltage
DC 24V
Output current
3A
Conmmunication interface
RS-485
Touch screen size
7 inch (6~16 channels）/ 10 inch (20 channels）
Size
240x200x70mm

Material QualityMaterial Quality

Material
Aluminum
