VSR-1EL - Pressure Regulator
Pressure Regulator
Pressure Regulator
Product FeaturesProduct Features
  • Line mounting pressure regulator
  • Brass chrome plated body and bonnet for inert, reactive, flammable and oxidizing gas and mixtures up to grade 6.0
  • Stainless steel 316L body and bonnet for corrosive gases
  • 4 ports flexible configuration
  • Stable outlet pressure
  • Simple outlet pressure limitation by handwheel
  • Tested for use with oxygen
ParameterParameter
  • Inlet pressure P1
    max. 100bar
  • Outlet pressure P2
    VAC/2/4/8/10/20 bar
  • Inlets and Outlets
    1/4”NPT(F)
  • Temperature range
    -30℃ to +74℃
  • Leak rate (to atmosphere)
    1x10-8mbar I/s He
  • Leak rate (Via seat)
    1x10-6mbar I/s He
  • Flow capacity
    Cv=0.18
Material QualityMaterial Quality
  • Body
    316L / Chrome Plated Brass
  • Valve seat
    PCTFE
  • Diaphragm
    Hastelloy® C276
  • Filter
    SS 316L
