VSR-4L - Pressure Regulator
Pressure Regulator
Pressure Regulator
Product FeaturesProduct Features
  • Low pressure, High flow regulator
  • Brass chrome plated body for inert, reactive, flammable and oxidizing gas and mixtures up to grade 6.0
  • Stainless steel 316L body for pharmaceutical, food, and beverage application
  • 4 ports flexible configuration
  • Stable outlet pressure
  • Tested for use with oxygen
ParameterParameter
  • Inlet pressure P1
    max. 35 bar
  • Outlet pressure P2
    2/3/4/8/10/20 bar
  • Inlets and Outlets
    see ordering info
  • Temperature range
    -15℃ to +74℃
  • Leak rate
    bubble-tight
  • Flow capacity
    Cv=5.1
Material QualityMaterial Quality
  • Body
    316L / Chrome Plated Brass
  • Valve seat
    EPDM (Buna-N 可选)
  • Diaphragm
    PTFE+Neoprene
Download
