VSR-12HL - Pressure Regulator

Pressure Regulator

Pressure Regulator

Product FeaturesProduct Features

Low pressure, high flow regulator
Brass chrome plated body for inert, reactive, flammable and oxidizing gas and mixtures up to grade 6.0
Stainless steel 316L body for pharmaceutical, food, and beverage application
4 ports flexible configuration
Stable outlet pressure
Tested for use with oxygen
Large seat and diaphragm areas provide high capacity with sensitive control of delivery pressure with low falloff

ParameterParameter

Inlet pressure P1
max. 35 bar
Outlet pressure P2
1/2/4/8/10/20 bar
Inlets and Outlets
see ordering info
Temperature range
-15℃ to +74℃
Leak rate
Bubble-tight
Flow capacity
Cv=3.1

Material QualityMaterial Quality

Body
316L / Diaphragm
Valve seat
EPDM (Viton® optional)
Diaphragm
PTFE+Buna-N
