VSR-7 - High Pressure Self-venting Regulator

High Pressure Self-venting Regulator

High Pressure Self-venting Regulator

Product FeaturesProduct Features

High pressure, high flow regulator
Brass chrome plated body and bonnet for inert, reactive, flammable and oxidizing oxidizing gas and mixtures up to grade 6.0
Stainless steel 316L body for pharmaceutical, food and beverage application
Simple outlet pressure limitation by handwheel
Self-venting standard
Stable outlet pressure
Tested for use with oxygen

ParameterParameter

Inlet pressure P1
max. 300 bar
Outlet pressure P2
20/35/50/100/170 bar
Inlets and Outlets
1/4”, 1/2” NPT(F)； 3/4”, 1” NPT(F)
Temperature range
-30℃ to +74℃
Leak rate
Bubble-tight
Flow capacity
Cv=0.8； Cv=2.0(HF)

Material QualityMaterial Quality

Body
316L / Chrome Plated Brass
Valve seat
PCTFE
Filter
SS 316L
O-ring
Viton® (FKM)
Back-up ring
PTFE
Gaskets
PCTFE
