VSR-92 - Hydrogen Pressure Regulators
Hydrogen Pressure Regulators
Hydrogen Pressure Regulators
Product FeaturesProduct Features
  • High pressure on-board pressure reducer
  • Piston type high pressure input, is safe and reliable
  • High flow rate meets high power condition of hydrogen new energy
  • Multi-specification preset pressure optional
  • Porous design, convenient installation of accessories
ParameterParameter
  • Inlet pressure P1
    max. 350 bar / 700 bar
  • Outlet pressure P2
    Inlet 350 bar：6~13 bar； Inlet 700 bar：7~13 bar
  • Temperature range
    -40oC to +85oC
  • Leak rate
    Bubble-tight
Material QualityMaterial Quality
  • Body
    Aluminum
  • Valve seat
    Vespel®
  • O-ring
    EPDM
  • Piston
    Aluminum
  • Spring
    Piano wire
  • Filter
    120 μm / 2 μm 316L
Download
