VSP-36 - Automatic Change Over System
Automatic Change Over System
Automatic Change Over System
Product FeaturesProduct Features
  • Double-sided pressure control panels with automatic Change-over function for high flow rates
  • For non-corrosive technical gases
  • Single-stage type with balanced main valve
  • Modular design (to be extended to 2X2, 2X3 etc. cylinders / bundles)
  • Central filter in the regulator
  • Shut-off valves
  • Process gas and purge valve on the inlet pressure side
  • Suitable for inlet pressure values of up to 300 bar
  • Designed for use with oxygen
  • Safety pressure gauges
  • Adjustable outlet pressure
ParameterParameter
  • Inlet pressure P1
    max. 245bar (Brass) / 300bar (316L)
  • Outlet pressure P2
    20/40/60bar
  • Inlet connection
    1/4”NPT(F)(316L) 、1/2”NPT(F)(铜)
  • Outelt connection
    3/4”NPT(20mm不锈钢管)
  • Temperature range
    -30℃ to +74℃
  • Leak rate
    Bubble tight
Material QualityMaterial Quality
  • Body
    Brass / Chrome plated / 316L
  • Shut-off valve
    Brass / Chrome plated / 316L
  • Valve seat
    PCTFE
  • Filter
    Stainless steel
  • Mounting plates
    Stainless steel
  • O-ring
    Viton®(FKM) / Kalrez®(FFKM) option
