VSP-5A - Pressure Control Panels - Automatic Change Over System

Pressure Control Panels - Automatic Change Over System

Pressure Control Panels - Automatic Change Over System

Product FeaturesProduct Features

Pressure control panel with automatic change-over function
VSR-1E Series single-stage regulator
Brass chrome plated body for inert, reactive, flammable and oxidizing gas and mixtures up to grade 6.0
Stainless steel 316L body and bonnet for corrosive gases
Modular design
Diaphragm type shut-off valves
Suitable for inlet pressure up to 300 bar
Compact disign for easy installation into safety cabinets
Tested for use with oxygen

ParameterParameter

Inlet pressure P1
max. 300 bar
Outlet pressure P2
2/4/10/20/35/50 bar
Temperature range
-30℃ to +74℃
Leak rate (to atmosphere)
1x10-8 mbar I/s He
Leak rate (via seat)
1x10-6 mbar I/s He

Material QualityMaterial Quality

Body
316L / Chrome Plated Brass
Valve seat
PCTFE
Diaphragm
Hastelloy® C276
Filter
SS 316L
