VSP-9 - Automatic Pressure Control Box

Automatic Pressure Control Box

Automatic Pressure Control Box

Product FeaturesProduct Features

Pressure control box with automatic switching function
Digital display cylinder pressure and provide replacement reminder
Audible and visual alarm, emergency cut-off
Suitable for flammable gases
Pneumatic diaphragm valve control
Modular design, convenient maintenance
Suitable for inlet pressure up to 300 bar
Compact structure, easy installation
Tested for use with oxygen

ParameterParameter

Inlet pressure P1
Max. 300 bar
Outlet pressure P2
2/4/10/20/35/50 bar
Temperature range
-30℃ to +74℃
Leak rate（to atmosphere）
1x10-8 mbar l/s He
Leak rate（Via seat）
1x10-6 mbar l/s He

Material QualityMaterial Quality

Body
316L / Chrome plated brass
Valve seat
PCTFE
Diaphragm（regulator）
Hastelloy®C276
Diaphragm（valve）
Elgiloy®
Filter
SS 316L
